Pressure Reducing Valve

Dome Loaded Regulator (44)

NU-TECH Dome Loaded Regulator is piston-sensed, dome-loaded, and positive-biased. The positive bias provides a constant outlet pressure from 50–1500 PSI greater than the reference pressure. With its self-vented feature, outlet pressure can be vented through the regulator, enabling downstream regulation even as the reference pressure decreases.

Get Quote →

01 / 00

Specifications

Media	All gases and liquids compatible with materials of construction
Max. Inlet Pressure	5000 psig
Outlet Pressure Range	50–1500 psig
Design Proof Pressure	7000 psig
Design Burst Pressure	8000 psig
Inlet Size	1/4", 3/8", 1/2" NPT/BSP
Flow Capacity	Main valve Cv = 0.7, Vent valve Cv = 0.35
Materials	Body – SS304 / SS316 (adjustable)
Operating Temperature	-17°C to 170°C
Trims	Stainless Steel
Leakage	Bubble Tight CL VI
